Abb TEY335 Mccb 3p 35a Bolt-on

Product Description

The ABB TEY335 is a one-inch wide per pole, compact, bolt-on circuit breaker for use on grounded 480Y/277 Vac systems. The bolt-on mounting base accessory makes the TEY suitable for varied applications as a lug-lug breaker. All TEY circuit breakers feature Quick-make / Quick-break mechanisms and easy to spot trip indication to ensure safety and reliability.

• Quick-make / Quick-break mechanisms
• Common trip bars
• Easy to spot trip indication

Product Highlights

Suitable for varied applications as a lug-lug breaker. Features common trip bars, and easy to spot trip indication to ensure safety and reliability.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: TEY335

Technical Specifications

• Category: Lighting Panel Circuit Breakers
• Product Line: TEY / Q-Line (Bolt-On)
• GO Schedule: EY
• Trip Style: Non-Interchangeable
• Poles: 3
• Amperage: 35 A
• System Voltage: 480Y/277 Vac
• Frame Type: TEY
• 120 Vac Interrupting Rating: 65 KAIC
• 120/240 Vac Interrupting Rating: 65 KAIC
• 240 Vac Interrupting Rating: 65 KAIC
• 277 Vac Interrupting Rating: 14 KAIC
• Trip Function: LI
• Continuous Current Rated: Standard
• Suitable for Reverse Feed: Yes
• Long Time: Fixed
• Instantaneous: Fixed
• Current Metering: No
• Protective Relays: No
• Special Markings: HACR
• HID: HID
• Wire Range (Cu/Al): 14-8 kcmil / 12-8 kcmil
• Brand: ABB / General Electric
• Series: TEY
• Phase: 3
• AIC Rating: 65kA @ 120VAC, 65kA @ 240VAC, 14kA @ 480Y/277VAC
• Mounting Style: Bolt-On
• Terminal Type: Copper/Aluminum Load Lug, Bolt-On
• For Use With: GE A-Series Lighting Panelboards, GE AE Lighting Panelboards, GE AS Lighting Panelboards
• Trip Technology: Thermal Magnetic
• Trip Adjustability: Fixed
• Wire Gauge: 10-4 AWG (Cu/Al)
• Max Wire: 4 AWG
• Min Wire: 10 AWG
• Available Options: Padlock Attachment, Mounting Base
• Accessories: Load Side Lugs Included
• Standards: CSA C22.2 No. 5, UL 489
• Approval: UL, CUL
• Temp Rating: 40C
• Construction Features: HACR Rated, HID Rated, Common Trip, Quick-Make/Quick-Break
• Maximum Amperage: 35A
• Number of Phases: 3
• Number of Poles: 3
• MPN: TEY335
• Application: Commercial, Industrial
• Volts AC: 480, 277
• Family / Style: E150
• Mounting: Bolt On
• Interrupt Rating AC: 14 kA
• Voltage Rating: 480 Star/277 Volt AC
• Interrupting Rating: 65 Kiloamp at 240 Volt AC, 14 Kiloamp at 277 Volt AC, 14 Kiloamp at 480 Star/277 Volt AC
• Maximum AC Voltage Rating: 480 Star/277 Volt
• Type: Molded Case, Thermal Magnetic
