Abb TCU35 Universal Raintight Hub 3.5 Inches Large Base

Product Description

The ABB TCU35 is a large-base universal raintight hub designed for use with ABB load centers and panels in outdoor enclosure applications. With a hub diameter of 3.5 inches and a base size of 4 inches, this fitting provides a weathertight conduit entry point rated for raintight service. Licensed electricians install this hub to protect conduit entries on outdoor electrical enclosures from moisture intrusion, helping maintain the integrity of the installation in exposed or wet-location environments.

The TCU35 is intended for use on 40-circuit and 42-circuit ABB load center units installed in R8 boxes only. This makes it a purpose-matched component for specific panel configurations where a large-base hub entry is required. It is well suited for residential and light commercial electrical installations where outdoor panels require raintight conduit connections.

Key Features

• Raintight rating suitable for outdoor enclosure applications
• Hub diameter of 3.5 inches for large conduit entries
• Base size of 4 inches for secure panel mounting
• Compatible with 40-circuit and 42-circuit configurations in R8 boxes
• Part of the ABB universal hub series covering a range of panel sizes

Compatibility

The TCU35 is rated for use with 40-circuit and 42-circuit ABB load center units in R8 boxes only. It is part of the ABB universal raintight hub series, which covers a variety of sizes for ABB load centers and panels.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the panel and verify zero voltage before opening the enclosure or working near any bus or wiring. Ensure the hub is properly seated and secured to maintain the raintight rating of the enclosure. Confirm the enclosure and box type are R8-compatible before installing the TCU35.

Technical Specifications

• Hub Diameter: 3.5 inches
• Base Size: 4 inches
• Compatible Circuit Counts: 40-circuit and 42-circuit units
• Box Type: R8 boxes only
• Enclosure Rating: Raintight
• UPC: 783164448979

Standard Information

• Brand: ABB
• Manufacturer Part Number: TCU35
