Abb TC2228S Tumbler Switch 2-pole

Product Description

The ABB TC2228S is a 2-pole tumbler switch designed for use in electrical control and switching applications. Tumbler switches of this type provide a reliable mechanical switching action through a lever-actuated toggle mechanism, making them a common choice for panel-mount and enclosure installations. Electricians and control technicians install this switch to open or close two independent circuits simultaneously, a configuration suited to multi-phase or dual-circuit control needs. Its compact form factor and straightforward actuator style simplify integration into new builds and retrofit projects alike.

This switch is applicable in light commercial and residential electrical panels, control enclosures, and equipment installations where a 2-pole switching function is required. It is well suited for use by licensed electricians performing panel work, control panel assembly, and equipment wiring in compliance with applicable NEC requirements. The 2-pole configuration makes it a practical option wherever simultaneous switching of two circuit legs is necessary.

Key Features

• 2-pole switching configuration allows simultaneous control of two circuit legs
• Tumbler-style actuator provides positive, tactile switching action
• Compact design suitable for panel-mount and enclosure installations
• Manufactured by ABB, a recognized name in electrical switching components

Compatibility

Designed as an OEM-style replacement or direct-install component for 2-pole tumbler switch applications in residential and light commercial electrical enclosures and control panels.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the circuit before removing or installing this switch. Verify that the circuit load and voltage ratings are within the switch specifications before energizing. Do not modify the switch body or actuator mechanism.

Technical Specifications

• Configuration: 2-Pole
• Switch Type: Tumbler
• UPC: 78316414586

Standard Information

• Brand: ABB
• Manufacturer Part Number: TC2228S
