Abb st202m-k10 miniature circuit breaker k-char., breaker breaker

Product Description

The ABB ST202M-K10 is a miniature circuit breaker designed for supplementary protection. It is compatible with System pro M compact accessories. This thermal/magnetic breaker is suitable for various applications and markets, offering a broad range of options and international approvals. It provides protection up to 480 Y / 277 VAC and 125 VDC.

• DIN Rail Mounting
• K Curve
• 2 Pole

Product Highlights

The ABB ST202M-K10 miniature circuit breaker provides reliable supplementary protection with a K curve trip characteristic.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: ST202M-K10

Technical Specifications

• Type: CIRCUIT BREAKERS
• UNSPSC Code: 39121603
• Brand: ABB
• Characteristic: K Curve
• Current Rating: 10 A
• Manufacturer Part Number: ST202M-K10
• Mounting Type: DIN Rail Mount
• Number of Poles: 2
• Series: ST200 M Series
• Termination: screw
• UPC Code: 4016779022422
• Voltage Rating: 480/277 V
• Product Series: ST200M
• Family Series: ABB Circuit Breakers, ST200M Series
• Poles: 2
• Max Voltage: 125 VDC, 277/480 VAC
• Trip Curve: K
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Neutral Pole: No
• Terminal Type: Screw
• Auxiliary Switch: Optional
• Shunt Trip: Optional
• Undervoltage Release: Optional
• Alarm Switch: Optional
• UL Standard: 1077
• Approvals: CCC, CSA, EAC, UL, VDE
• Amps: 10
• Volts AC: 277, 480Y
• Interrupt Rating AC: 10 kA
• Amperage: 10 Amps
