Abb st201m-k3 Circuit Breaker, Miniature, Din Rail Mount, K Curve, 1 Pole, 3A

Product Description

The ABB ST201M-K3 miniature circuit breaker provides supplementary protection up to 480 Y / 277 VAC and 125 VDC. It is fully compatible with System pro M compact accessories. These circuit breakers have a delayed thermal tripping mechanism for overload protection and an electromechanic tripping mechanism for short circuit protection.

• DIN Rail Mount
• Suitable for residential, commercial and industrial applications
• Supplementary protection up to 480 Y/277 V AC and 125 V DC

Product Highlights

The ABB ST201M-K3 miniature circuit breaker is ideal for multiple applications and markets. It complies with IEC/EN 60898-1 and IEC/EN 609 47-2.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: ST201M-K3

Technical Specifications

• Manufacturer Part Number: ST201M-K3
• Manufacturer: ABB
• Mounting Type: DIN Rail Mount
• Number of Poles: 1
• Series: ST200 M Series
• Voltage Rating: 277 V
• UPC Code: 4016779017688
• Type: Thermal/Magnetic
• Approvals: CSA 22.2 No. 235, UL 1077
• Termination: screw
• Standards: CSA 22.2 No. 235, UL 1077
• Current Rating: 3 A
• Characteristic: K Curve
• Volts AC: 277, 480Y
• Mounting: DIN Rail
• Poles: 1
• Amps: 3
• Interrupt Rating AC: 10 kA
