Abb S202MUC-K10 Miniature Circuit Breaker, 10A, 2 Pole, K Curve, 400 VAC, 440 VDC

Product Description

The ABB S202MUC-K10 miniature circuit breaker extends the ABB System proM compact product range with an MCB for DC and AC applications. The S 200 MUC has a high inbuilt short circuit breaking capacity and is flexible for AC and DC application. It also has approval and compliance in accordance with all major international and local standards.

• MCB for DC and AC applications
• High inbuilt short circuit breaking capacity
• Flexible AC and DC application

Product Highlights

The S202MUC-K10 is a simple and flexible solution for warehousing or project engineering, planning, installing or maintaining your equipment.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: S202MUC-K10

Technical Specifications

• Actuator Type: Toggle
• Brand: ABB
• Characteristic: K Curve
• Current Rating: 10 A
• Manufacturer Part Number: S202MUC-K10
• Mounting Type: DIN Rail Mount
• Number of Poles: 2 Pole
• Series: S200M Series
• Manufacturer: ABB
• Product Series: S200MUC
• Family Series: ABB Circuit Breakers, S200MUC Series
• Max Voltage: 500 VDC
• Trip Curve: K
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting: DIN Rail
• Neutral Pole: No
• Terminal Type: Screw
• Auxiliary Switch: Optional
• Shunt Trip: Optional
• Undervoltage Release: Optional
• Alarm Switch: Optional
• UL Standard: 1077
• Approvals: CSA, UL
• Category: Mini Circuit breakers
• Interrupting Rating acc. to UL1077: (500 V DC) 10 kA (480Y / 277 V AC) 6 kA
• Power Loss: 3.9 W
• at Rated Operating Conditions per Pole: 1.96 W
• Product Main Type: S200MUC
• Rated Current: 10 A
• Rated Ultimate Short-Circuit Breaking Capacity: (220 V DC) 25 kA (440 V AC) 10 kA (440 V DC) 10 kA
• Rated Voltage (V): (500 V DC) (480Y / 277 V AC)
• Standards: CSA 22.2 No. 235 IEC/EN 60947-2 UL 1077
