Product Description
The ABB RCC21 is a nylon insulated butt splice connector designed for use with twelve to ten AWG conductors. It features a length of one point twenty-six inches and is rated for six hundred VAC. The construction includes copper with a yellow color coding for size identification.
- Nylon insulated with electro-tin plating
- Wires are laid side by side and crimp connection finalizes in one motion
- Color coded to match wire sizes
Product Highlights
This connector meets military specifications and is suitable for various applications in electrical wiring. It is designed to ensure reliable connections while maintaining safety standards.
Product Information
Standard Information
-
Manufacturer: ABB - Installation Products
-
UPC: 78621082050
Technical Specifications
-
Conductor Size: 12 to 10 AWG
-
Length: 1.26 inches
-
Voltage Rating: 600 VAC
-
Temperature Rating: 105 degrees C
-
Material: Copper
-
Color: Yellow
-
Finish: Electro-TiN Plated
-
Standards/Approvals: CSA Certified, UL 94 V-2, MIL-T-7928
