ABB RC713 Thomas & Betts RC713 Nylon-Insulated Ring Terminal - #12-10, 1/4bolt (500/Box)

Product Description

The ABB RC713 is a nylon-insulated ring terminal suitable for wire ranging from #12 to #10 AWG. Designed for a secure connection with a bolt hole of one-quarter inch, it ensures reliable performance with a maximum insulation diameter of two hundred ten thousandths of an inch.

• Packaged in five hundred units for bulk use.
• Features tin-plated copper for enhanced conductivity.
• Temperature rating up to one hundred five degrees Celsius.

Product Highlights

This ring terminal features a self-insulated design that provides high dielectric strength through the nylon sleeve. An inner bronze insulation grip sleeve enhances flexibility, preventing conductor creep.

Product Information

Standard Information

• Brand: ABB
• Manufacturer: Thomas & Betts Co.

Technical Specifications

• Voltage: 600 Volt
• Insulation Type: Insulated Nylon
• Stud Size: 1/4 inch
• Material: Copper
• Finish: Tin Plated
• Temperature Rating: 105 degrees C
• Conductor Size: 12-10 AWG
• Standard: UL E9809
