Product Description
The ABB RC10-14 is a nylon-insulated ring terminal designed for #12-10 AWG wires with a 1/4 inch bolt hole. This terminal allows for secure electrical connections and is suitable for various applications. It features a durable construction for reliable performance.
- Width: 1.3 inches
- Length: 1.12 inches
- Maximum insulation diameter: 0.21 inches
Product Highlights
This ring terminal is self-insulated with nylon sleeves that provide dielectric strength. It offers an inner grip sleeve that enhances the flexibility of the conductor.
Product Information
Standard Information
-
Brand: ABB
-
Manufacturer: Thomas & Betts Co
Technical Specifications
-
Conductor Size: 12-10 AWG
-
Stud Size: 1/4 inch
-
Voltage Rating: 600 VAC
-
Temperature Rating: 105 degrees C
-
Material: Copper
-
Insulation Type: Nylon
