ABB - R208CP6HP MEP PEDESTAL RNGLESS 200A W/BRKR PROVISIONS

Product Description

The Midwest Electric R208CP6HP is a metered pedestal that features a ringless inline and head post suitable for residential applications. This unit operates at 120/240 VAC and has a capacity of 200 amps. It can accommodate wire sizes ranging from six AWG to three hundred fifty kcmil, as well as twelve to two AWG wire. It is designed for underground or loop feed installations and is housed in a NEMA 3R enclosure made from G90 galvanized steel, ensuring durability.

• Rated for 200 amps and compatible with various wire sizes.
• Constructed with G90 galvanized steel for enhanced protection.
• Allows for easy surface or semi-flush mounting.

Product Highlights

This product is ideal for single-family residences and mobile homes as an electrical service entrance solution.

Product Information

Standard Information

• Manufacturer: ABB - Midwest Electric
• Voltage Rating: 120/240 VAC

Technical Specifications

• Amperage Rating: 200 A
• Application: Residential, Construction, Single Family Residences and Mobile Home Applications
• Circuit Breaker Type: CB2200B
• Enclosure: NEMA 3R
• Feed Type: Underground/Loop
• Material: G90 Galvanized Steel
• Mounting Type: Surface
• Phase: 1 ph
• Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL Listed
• Type: Metered Ringless
