ABB - P065F MEP 60A FUSIBLE DISC

Product Description

ABB - Midwest Electric, MPN P065F, is a fused pull-out AC disconnect switch. It is rated for 120/240 VAC and can handle 60 Amperes. This switch is designed for one phase and includes two poles. It features a 10 kA short circuit rating and comes in a NEMA 3R enclosure suitable for outdoor use.

• Pullers are removable in the OFF position for user safety.
• Padlock provisions on the door prevent unauthorized access.
• Noryl thermoplastic enclosure provides corrosion resistance and durability.

Product Highlights

This switch is widely used in HVAC systems to disconnect power safely. It allows for easy access to electrical components during maintenance.

Product Information

Standard Information

• Manufacturer: ABB - Midwest Electric
• UPC: 78456730007

Technical Specifications

• Amperage Rating: 60 A
• Dimensions: 8 inches H x 5-3/4 inches W x 3-1/8 inches D
• Enclosure: NEMA 3R
• Horsepower: 10 hp
• Material: Noryl/Thermoplastic
• Mounting Type: Surface
• Number of Poles: 2
• Phase: 1
• Short Circuit Current Rating: 10 kA
• Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, cUL/UL Listed
• Voltage Rating: 120/240 VAC
