ABB LCN10 Blackburn Compression Terminal 35kV (2-Hole)

Product Description

The ABB LCN10 is a compression terminal designed for effective wire termination. This terminal features a long barrel design suited for copper conductors and is capable of handling a maximum voltage of thirty-five kilovolts. The terminal is designed to accommodate wire sizes of one/zero AWG and is compatible with a half-inch bolt hole. It also comes with a tin plating that enhances its corrosion resistance.

• Designed for copper conductors including AWG, stranded, and welding cable.
• UL listed for use with recognized installation tools.
• Color-coded for easy die identification.

Product Highlights

The ABB LCN10 ensures reliable connections in industrial and building applications, offering high conductivity and durability.

Product Information

Standard Information

• Brand: ABB
• Manufacturer: Blackburn / Thomas & Betts

Technical Specifications

• Type: Long Barrel
• Material: Copper
• Color: Pink
• Voltage Rating: 35 kV
• Stud Size: 1/2 in
• Cable Size: 1/0 AWG
• Overall Length: 3-31/32 in
• Barrel Length: 1-1/32 in
• Number of Holes: 2 Hole
