Product Description
The ABB Electrification TH4324R is a fused heavy-duty safety switch. It operates at 240 volts and supports an amperage rating of 200 A. Designed for commercial and industrial settings, it ensures high performance and operational safety.
- Fused design for enhanced safety
- Rated for 25 horsepower
- NEMA 3R enclosure for outdoor use
Product Highlights
This switch is compatible with class H, J, K, or R fuses and includes visible ON/OFF labels for safety.
Product Information
Standard Information
-
Manufacturer: ABB Electrification
-
Product Link: View Product
Technical Specifications
-
Actuator Type: Handle
-
Amperage Rating: 200 A
-
Application: Commercial, Industrial, Electrical Distribution and Control Applications
-
Dimensions: 14.3 in W x 9.5 in D x 31.7 in H
-
Enclosure: NEMA 3R
-
Finish: Hot Dipped Galvanized/Powder Coated
-
Frequency Rating: 50/60 Hz
-
Horsepower: 25 hp
-
Manufacturer Part Number: TH4324R
-
Material: Stainless Steel
-
Mounting Type: 3-Point/Self-Leveling
-
Number of Poles: 3
-
Number of Wires: 4
-
Phase: 3 Ph
-
Short Circuit Current Rating: 200 kA
-
Standards/Approvals: CSA C22.2 No. 4-04|cUL Listed|Federal Specification WS865C|Seismic Certified|UL Listed
-
Temperature Rating: 60 to 75 deg C
-
Terminal Type: Line/Load Lug
-
Voltage Rating: 240 VAC
