ABB Electrification TG3225 Safety Switch 400A-240V-2-FUSE NEMA 1

SKU: TG3225
Availability: In Stock
truck-svgrepo-com

Ships via Freight in 3-5 Business Days

$1,909.47
$1,909.47
Manuals:
LTL Delivery

This product weighs 102 lbs and may require the use of lift gate. If you require a lift gate you will have the option to add one FREE of charge at checkout.

HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The ABB Electrification TG3225 is a fused general duty safety switch designed for residential and light commercial applications. It has a voltage rating of two hundred forty volts and an amperage rating of four hundred amps. This safety switch features a durable NEMA 1 enclosure suitable for indoor use.

  • Fused switch with handle actuator
  • Designed for three phase systems
  • Quick-make, quick-break mechanism for reliable operation

Product Highlights

This device is excellent for electrical distribution and control applications and meets numerous safety standards, offering peace of mind during electrical installations. Its robust design ensures long-term use in various environments.

Product Information

Standard Information

  • Manufacturer: ABB Electrification
  • Product Name: GE TG3225 400A-240V-2-FUSE NEMA 1 Safety Switch

Technical Specifications

  • Actuator Type: Handle
  • Amperage Rating: 400 A
  • Application: Residential, Light Commercial, General, Electrical Distribution and Control Applications
  • Dimensions: 21.6 inches W x 8.7 inches D x 49.44 inches H
  • Enclosure: NEMA 1
  • Frequency Rating: 50/60 Hz
  • Horsepower: 50 hp
  • Material: Steel
  • Mounting Type: 3-Point/Self-Leveling
  • Number of Poles: 2
  • Number of Wires: 3
  • Phase: 3 ph
  • Short Circuit Current Rating: 10 kA
  • Temperature Rating: 60/75 degrees C
  • Voltage Rating: 240 VAC
