Abb E996G Box Adapter 1.25 Inch Pvc Schedule 40 80

Product Description

The ABB E996G is a PVC box adapter designed to connect conduit runs to electrical outlet boxes, junction boxes, or enclosures in standard conduit installations. Sized at 1.25 inches with an outer diameter of 1.660 inches and a length of 1.25 inches, this adapter provides a secure mechanical transition between conduit and box knockouts. Constructed from PVC in a gray finish, it is rated for use with Schedule 40 and Schedule 80 conduit systems. Electricians and electrical contractors install this fitting as part of raceway assemblies in both new construction and retrofit applications.

This box adapter is suited for residential and commercial electrical installations where PVC conduit terminates at an electrical enclosure or box. It is compatible with Schedule 40 and Schedule 80 PVC conduit at the 1.25-inch trade size, making it a standard fitting in conduit runs that require a clean, code-compliant box entry. Typical installation environments include exposed or concealed indoor wiring, as well as wet or damp locations where PVC conduit is the preferred raceway material.

Key Features

• Trade size of 1.25 inches fits standard knockout openings
• Outer diameter of 1.660 inches for precise box entry fit
• Length of 1.25 inches provides adequate thread engagement
• PVC construction offers corrosion resistance and electrical non-conductivity
• Gray color matches standard PVC conduit and fittings
• Compatible with both Schedule 40 and Schedule 80 PVC conduit

Compatibility

Designed for use with Schedule 40 and Schedule 80 PVC conduit systems at the 1.25-inch trade size.

Installation Notes

Installation is performed by a licensed electrician in accordance with applicable NEC requirements for PVC conduit systems. De-energize all circuits in the affected raceway before beginning work. PVC solvent cement is typically used to secure conduit fittings; allow adequate cure time before pulling wire. Do not over-torque the locknut when securing the adapter to the box, as PVC threads can crack under excessive force.

Technical Specifications

• Trade Size: 1.25 inches
• Length: 1.25 inches
• Outer Diameter: 1.660 inches
• Material: PVC
• Color: Gray
• Conduit Schedule Compatibility: Schedule 40 and Schedule 80

Standard Information

• Brand: ABB
• Manufacturer Part Number: E996G
