Abb E950HF-CAR Reducer Bushing 1.5x1 Inch Schedule 40 Pvc

Product Description

The ABB E950HF-CAR is a reducing bushing designed for use in Schedule 40 rigid non-metallic conduit systems. It steps down a 1.5-inch conduit opening to accept a 1-inch conduit, allowing tradespeople to transition between conduit sizes within a single raceway run. The bushing is manufactured to fit the Schedule 40 PVC conduit standard, providing a secure mechanical connection at the reduction point. Licensed electricians install this fitting as part of conduit infrastructure in new construction, renovation, and service upgrade work where conduit size changes are required.

This reducing bushing is suited for residential and light commercial electrical installations where rigid non-metallic conduit is the raceway of choice. It is commonly installed in conduit runs routed through walls, ceilings, underground enclosures, or exposed locations where PVC conduit is permitted by the local authority having jurisdiction. The fitting integrates into standard Schedule 40 non-metallic conduit assemblies without special tooling.

Key Features

• Reduces 1.5-inch conduit to 1-inch conduit in a single fitting
• Rated for Schedule 40 rigid non-metallic conduit systems
• Designed for use in rigid PVC conduit raceways
• Compact bushing profile for use in junction boxes and conduit bodies

Compatibility

Designed as an OEM-style replacement fitting for Schedule 40 rigid non-metallic conduit systems requiring a 1.5-inch to 1-inch reduction.

Installation Notes

Installation is performed by a licensed electrician in accordance with NEC Article 352 governing rigid PVC conduit. De-energize all circuits in the conduit run before beginning work. PVC conduit cement appropriate for Schedule 40 fittings should be used to secure the bushing where a solvent-weld connection is required. Do not over-ream the conduit opening, as a proper fit is necessary for a secure connection.

Technical Specifications

• Inlet Size: 1.5 inches
• Outlet Size: 1 inch
• Conduit Schedule: Schedule 40
• Conduit Type: Rigid Non-Metallic
• UPC: 03448113050

Standard Information

• Brand: ABB
• Manufacturer Part Number: E950HF-CAR
