Abb E950FD-CAR Conduit Reducer Bushing 1x1/2 Inch Sch 40

Product Description

The ABB E950FD-CAR is a rigid non-metallic reducing bushing designed for use in Schedule 40 PVC conduit systems. It reduces a 1-inch conduit opening down to a 1/2-inch fitting connection, allowing installers to adapt between two conduit sizes within the same run. This type of bushing is a standard component in electrical conduit assemblies and is installed by licensed electricians during rough-in and finish wiring on both new construction and retrofit projects. The non-metallic PVC construction resists corrosion and moisture, making it well suited for wet, damp, and underground applications.

This reducer bushing is used in residential, commercial, and light industrial electrical installations wherever a conduit size transition is needed. It fits into Schedule 40 PVC conduit systems and is commonly used in panel feeds, junction box entries, and conduit runs that change trade size. Electricians working with PVC conduit systems in wet locations, slab pours, or direct-burial applications will find this a routine replacement or new-install component.

Key Features

• Reduces 1-inch conduit to 1/2-inch fitting connection
• Compatible with Schedule 40 PVC rigid non-metallic conduit
• Non-metallic construction resists corrosion, moisture, and chemical exposure
• Standard bushing profile for straightforward installation without special tools
• Suitable for wet, damp, and underground conduit applications

Compatibility

Designed as an OEM-style fitting for Schedule 40 rigid non-metallic PVC conduit systems requiring a 1-inch to 1/2-inch trade size reduction.

Installation Notes

Installation is performed by a licensed electrician in accordance with NEC requirements for conduit fittings and raceway systems. De-energize all circuits in the affected conduit run before beginning work. PVC conduit cement or solvent weld may be required depending on the fitting configuration and application. Inspect the bushing seating surface for debris before assembly to ensure a secure, code-compliant connection.

Technical Specifications

• Inlet Size: 1 inch
• Outlet Size: 1/2 inch
• Conduit Schedule: Schedule 40
• Conduit Type: Rigid Non-Metallic (PVC)
• Fitting Type: Reducing Bushing
• UPC: 03448113299

Standard Information

• Brand: ABB
• Manufacturer Part Number: E950FD-CAR
