Abb C-106-1/2 Pipe Strap 14 Gauge 0.5 Inch Steel Emt

Product Description

The ABB C-106-1/2 is a 14-gauge steel pipe strap designed to secure 0.5-inch pipe or electrical metallic tubing (EMT) to structural surfaces. This one-hole mounting strap provides a rigid, reliable anchor point for conduit runs in commercial and residential electrical installations. Fabricated from steel, it delivers the mechanical strength required for code-compliant conduit support. Electricians and electrical contractors use this strap when routing EMT through walls, ceilings, and framing members where a secure, low-profile fastening method is needed.

This strap is suited for use with 0.5-inch EMT conduit in standard electrical rough-in and retrofit applications. It is commonly installed during new construction, tenant improvement, and service upgrade work wherever EMT is the conduit of choice. The 14-gauge steel construction meets typical support-spacing requirements under the National Electrical Code for rigid and semi-rigid conduit systems.

Key Features

• 14-gauge steel construction for rigid conduit support
• Sized for 0.5-inch pipe or EMT conduit
• One-hole mounting design for fast, straightforward installation
• Compatible with EMT conduit systems in standard electrical applications
• Steel material suitable for indoor structural mounting surfaces

Compatibility

Designed for use with 0.5-inch EMT conduit as an OEM-style support strap in residential and commercial electrical conduit installations.

Installation Notes

Installation is performed by licensed electricians in accordance with NEC conduit-support spacing requirements. De-energize all circuits in the work area before securing conduit straps near live conductors. Use a fastener appropriate for the mounting surface, such as a machine screw for metal framing or a wood screw for lumber. Do not overtighten the mounting fastener, as deforming the strap can compromise the conduit hold.

Technical Specifications

• Gauge: 14
• Pipe Size: 0.5 inches
• Material: Steel
• Application: EMT Conduit
• UPC: 785991759693

Standard Information

• Brand: ABB
• Manufacturer Part Number: C-106-1/2
