ABB BG807L Steel City 2-1/2 Ground Bushing RGD/IMC DC Zinc In..

Product Description

ABB BG807L is a Steel City grounding bushing designed for use in rigid and intermediate metal conduits. This insulated grounding bushing accommodates a minimum wire size of fourteen AWG and a maximum wire size of one/zero AWG. The throat measures fifty-nine point one millimeters, while the diameter is eighty-two millimeters. It is constructed from die-cast zinc for durability.

• Insulated design for safe grounding
• Accommodates various wire sizes
• Durable die-cast zinc material

Product Highlights

The BG807L grounding bushing is suitable for electrical installations requiring reliable grounding solutions. It ensures a proper electrical connection while reducing the risk of damage to cables.

Product Information

Standard Information

• Application: Rigid/IMC Conduit
• Manufacturer: ABB - Installation Products

Technical Specifications

• Trade Size: 2-1/2 in
• Material: Die Cast Zinc
• Height: 38.25 mm
• Throat: 59.1 mm
• Series: BG Series
• Standards/Approvals: UL File No. E3060 | cULus Listed
• Maximum Wire Size: 1/0 AWG
• Minimum Wire Size: 14 AWG
• Lug Type: Lay-In
