ABB BG805L BG Series Insulated Grounding Bushing 1-1/2 in

Product Description

The ABB BG805L is an insulated grounding bushing designed for use in rigid or intermediate metal conduit applications. This bushing has a trade size of one and a half inches and accommodates wire sizes from fourteen to two AWG, making it versatile for different electrical needs.

• Constructed with die cast zinc for durability
• Features a lay-in lug for easy installation
• Specifically designed for electrical grounding applications

Product Highlights

This grounding bushing is part of the BG series and is suitable for use in a range of electronic installations.

Product Information

Standard Information

• Manufacturer: ABB - Installation Products
• UPC: 78599108867

Technical Specifications

• Series: BG Series
• Trade Size: 1-1/2 in
• Minimum Wire Size: 14 AWG
• Maximum Wire Size: 2 AWG
• Throat Diameter: 38.3 mm
• Height: 35 mm
• Application: Rigid/IMC Conduit
• Lug Type: Lay-In
• Material: Die Cast Zinc
• Standards/Approvals: UL File No. E3060|cULus Listed
