ABB BG803L Steel City 1 GND Bushing RGD/IMC DC Zinc Ins

Product Description

ABB BG803L is a Steel City Grounding Bushing designed for use with rigid and IMC conduit. This insulated bushing is suitable for connecting grounding conductors. The bushing accommodates a minimum wire size of fourteen AWG and a maximum wire size of four AWG.

• Compatible with rigid and IMC conduit
• Die cast zinc construction
• Features lay-in lug for easy wire connections

Product Highlights

This grounding bushing is essential for ensuring a reliable grounding connection in electrical systems. The durable construction meets industry standards.

Product Information

Standard Information

• Manufacturer: ABB - Installation Products
• UPC: 78599108865

Technical Specifications

• Application: Rigid/IMC Conduit
• Height: 27 mm
• Lug Type: Lay-In
• Manufacturer Part Number: BG803L
• Material: Die Cast Zinc
• Maximum Wire Size: 4 AWG
• Minimum Wire Size: 14 AWG
• Series: BG Series
• Standards/Approvals: UL File No. E3060, cULus Listed
• Throat: 24.5 mm
• Trade Size: 1 in
• Type: Insulated
