Abb B936 4 Hole Angle Plate Strut Fitting 50 Pack

Product Description

The ABB B936 is a 4-hole angle plate designed for use with standard strut channel framing systems. It provides a rigid 90-degree connection point between two runs of channel, allowing installers to build secure, load-bearing support structures for conduit, pipe, duct, and mechanical equipment. This fitting is a core component in strut-based support assemblies and is installed by electricians, pipefitters, and HVAC mechanics in both commercial and industrial applications. Each pack contains 50 individual angle plates, making it practical for larger jobs requiring multiple connection points.

The B936 angle plate is suited for use in commercial construction, industrial facilities, and mechanical rooms where strut channel framing is the specified support method. It works in both overhead and wall-mounted strut assemblies. Typical applications include supporting conduit runs, pipe hangers, cable tray systems, and HVAC equipment mounting frames. Its 4-hole configuration offers flexible bolt placement and secure fastening across a variety of structural orientations.

Key Features

• 4-hole design allows multiple fastening points for a rigid, stable connection
• 90-degree angle configuration for perpendicular strut channel connections
• Sold in a 50-piece pack, suitable for large-scale or multi-point installations
• Compatible with standard strut channel framing hardware and fittings
• Compact profile fits within typical mechanical and electrical support assemblies

Compatibility

Designed as an OEM-style fitting for use with standard 1-5/8-inch strut channel framing systems commonly found in commercial and industrial electrical, plumbing, and HVAC installations.

Installation Notes

Installation is typically performed by licensed electricians, pipefitters, or mechanical contractors. De-energize all nearby electrical systems and shut off relevant mechanical services before working in the installation area. Use appropriate hardware torque values specified by the strut system manufacturer when fastening channel fittings. Installations in electrical applications should comply with applicable NEC requirements for support and fastening.

Technical Specifications

• Hole Count: 4
• Package Quantity: 50 per pack
• Package Dimensions (L x W x H): 10.4 inches x 7.4 inches x 4.5 inches
• Package Weight: 40.38 pounds
• UPC: 78599175810

Standard Information

• Brand: ABB
• Manufacturer Part Number: B936
