Abb A220H Ent 45 Degree Elbow 1.5 Inch Fitting

Product Description

The ABB A220H is a 45-degree elbow fitting designed for use with Electrical Nonmetallic Tubing (ENT). This fitting allows installers to make smooth directional changes in ENT conduit runs without kinking or stressing the tubing. It is a standard conduit fitting used in low-voltage and branch-circuit wiring applications in both residential and light commercial construction. At 1.5 inches trade size, it accommodates common ENT used in framed wall and floor assemblies. Electricians install this fitting as part of a complete ENT conduit system where code-compliant raceway protection is required.

This fitting is used in residential and light commercial electrical installations where ENT is permitted by the NEC as a wiring method. Typical applications include interior wall framing, floor-to-ceiling transitions, and embedded conduit runs in concrete or similar encased assemblies where ENT is code-approved. The 45-degree angle makes it suited for offset routing around structural members or transitioning between angled surfaces without requiring field-bent tubing.

Key Features

• 45-degree elbow geometry for directional changes in ENT conduit runs
• 1.5-inch trade size fits standard ENT of the same nominal diameter
• Designed for use with Electrical Nonmetallic Tubing (ENT) systems
• Lightweight construction at 0.14 pounds
• Suitable for interior wiring applications per applicable NEC provisions

Compatibility

Designed as an OEM-style fitting for use with 1.5-inch Electrical Nonmetallic Tubing (ENT) conduit systems in standard residential and light commercial electrical installations.

Installation Notes

Installation is performed by a licensed electrician in accordance with NEC Article 362 governing Electrical Nonmetallic Tubing. De-energize all circuits in the work area before beginning conduit work. Ensure ENT is fully seated into the fitting bell and secured per manufacturer and code requirements. ENT and its fittings are not approved for all installation environments — verify suitability for the specific application before installation.

Technical Specifications

• Trade Size: 1.5 inches
• Fitting Angle: 45 degrees
• Conduit Type: Electrical Nonmetallic Tubing (ENT)
• Weight: 0.14 pounds
• UPC: 03448119084

Standard Information

• Brand: ABB
• Manufacturer Part Number: A220H
