Abb 60112-TB 4 Awg Green Single Hole Al Cu Lug

Product Description

The ABB 60112-TB is a 4 AWG grounding lug rated for use with both aluminum and copper conductors. Designed for single-hole panel or busbar mounting, this lug provides a secure, code-compliant termination point for grounding conductors in electrical distribution and control equipment. The green color coding identifies it as a grounding lug at a glance, reducing the risk of wiring errors during installation. Licensed electricians and panel technicians install this type of lug in residential, commercial, and light industrial applications where a reliable equipment grounding connection is required.

This lug is suited for grounding applications in load centers, distribution panels, and electrical enclosures. Its AL-CU dual rating makes it compatible with both aluminum and copper grounding conductors, which is especially useful in service entrance and feeder work where conductor material may vary by job. The single-hole mounting configuration allows straightforward attachment to a busbar or ground bar stud.

Key Features

• Rated for 4 AWG conductors in aluminum or copper
• Green color coding identifies grounding service per NEC convention
• Single-hole mounting for busbar or ground bar installation
• AL-CU dual rating supports both conductor material types
• Sold in a 100-piece outer pack for job-site and shop stocking

Compatibility

Designed as an OEM-style grounding lug for use in residential and commercial electrical panels, load centers, and distribution enclosures requiring a 4 AWG single-hole AL-CU ground termination.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize and lock out the panel before installing or replacing any lug. Strip conductor insulation to the manufacturer-specified length and seat the conductor fully before torquing the fastener. Do not mix dissimilar metals at the termination without a lug rated for dual AL-CU service, which this lug provides.

Technical Specifications

• Conductor Size: 4 AWG
• Conductor Material Compatibility: Aluminum and Copper (AL-CU)
• Mounting Holes: 1 (Single Hole)
• Color: Green (Grounding)
• Package Quantity: 100 per outer pack
• Package Weight: 2.5 pounds per 100 units
• Package Dimensions (L x W x H): 12.6 inches x 6.4 inches x 4.0 inches
• UPC: 78621060112

Standard Information

• Brand: ABB
• Manufacturer Part Number: 60112-TB
