ABB 58171 T&B 300WELD RED 1H COP LUG

Product Description

The ABB compression lug has a part number 58171. It is a non-insulated compression lug designed for copper conductors with a size of three hundred kcmil. This product features a peep hole for easier installation. It is part of the Color-Keyed compression system which ensures proper crimping onto the conductor by matching the right connector to the corresponding tool and die.

• Non-insulated design for optimal electrical connection
• Compatible with copper conductors up to three hundred kcmil
• Color-coded for easy identification of the suitable tool

Product Highlights

The Color-Keyed compression system provides reliable connections by using the correct tool and connector pairing. This enhances the installer’s confidence in their connections and efficiency in their work.

Product Information

Standard Information

• Manufacturer: ABB - Installation Products
• UPC: 78621058171

Technical Specifications

• Application: For providing a high degree of reliability in electrical wiring
• Barrel Size: 0.93 inches diameter
• Color: Red
• Conductor Size: 300 kcmil
• Conductor Type: Copper
• Die Code: 71
• Mounting Hole Size: 0.531 inches
• Overall Length: 2.85 inches
• Series: 58100
• Specifications: Tin Plated
• Standards/Approvals: CSA Certified | UL File No. E9809
• Stud Size: 1/2 inches
• Tongue Size: 1.25 inches L x 1.36 inches W x 0.18 inches thick
• Tongue Type: Straight
• Type: 1-Hole Non-Insulated
• Voltage Rating: 35 kV
