Abb 569B806G2 Circuit Numbering Strip 43-84

Product Description

The ABB 569B806G2 is a circuit numbering strip designed for use in A Series panelboards, covering circuit positions 43 through 84. This field-installed accessory provides clear, standardized circuit identification inside the panelboard directory, supporting accurate labeling and code-compliant documentation. It is a direct replacement part intended for installation by licensed electricians during new panelboard commissioning or service work on existing installations. The strip integrates with the panelboard door directory card holder to keep circuit labels organized and legible over the life of the installation.

This numbering strip is used in residential and light commercial electrical distribution panels where the A Series panelboard platform is installed. It is suited for applications requiring circuit identification beyond the standard lower-range strips, covering the upper half of larger capacity panels. The strip is a field-installed kit component, allowing technicians to replace worn or missing directory strips without replacing the full panelboard assembly.

Key Features

• Covers circuit positions 43 through 84 for upper-range panel directory labeling
• Designed as a field-installed replacement part for A Series panelboards
• Supports code-compliant circuit identification and panelboard documentation
• Drop-in fitment into the existing door directory card holder

Compatibility

Designed as an OEM-style replacement circuit numbering strip for ABB A Series panelboards requiring directory labeling for circuit positions 43 through 84.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements for panelboard labeling and circuit identification. De-energize the panel and follow lockout/tagout procedures before opening the panelboard door or accessing interior components. The strip slides or clips into the door-mounted directory card holder; no tools are typically required for the strip replacement itself. Verify that the numbering range matches the actual circuit positions in the installed panelboard before completing the directory.

Technical Specifications

• Circuit Range: 43 to 84
• UPC: 783175108480

Standard Information

• Brand: ABB
• Manufacturer Part Number: 569B806G2
