Abb 54509 Copper Compression Connector 1/0 Awg 2-way

Product Description

The ABB 54509 is a 2-way copper compression connector rated for 1/0 AWG conductors, color-coded pink for quick gauge identification in the field. This connector is designed for making reliable, low-resistance splices between copper conductors in electrical distribution and wiring applications. Compression-style terminations deliver consistent contact force without the variability of mechanical set-screw designs. Licensed electricians and wiremen are the primary installers. Sold in a 100-piece outer pack, the 54509 suits high-volume rough-in work, service upgrades, and panel feed installations where 1/0 AWG copper is specified.

The ABB 54509 is suited for residential and light commercial electrical work wherever 1/0 AWG copper conductors require a straight or inline splice. The pink color coding allows installers to verify conductor size compatibility at a glance, reducing mis-termination on jobsites where multiple wire gauges are in use simultaneously. The 100-piece pack format is practical for contractors stocking service trucks or supply rooms for larger projects.

Key Features

• Compression-style copper connector for secure, low-resistance terminations
• Rated for 1/0 AWG copper conductors
• Pink color coding for fast gauge identification in the field
• 2-way design for inline conductor splicing
• Copper construction for compatibility with copper wiring systems
• Packaged 100 pieces per outer pack for jobsite or shop stocking

Compatibility

Designed for use with 1/0 AWG copper conductors. Verify conductor material and gauge match connector specifications before installation.

Installation Notes

Compression connectors of this type are installed by licensed electricians using a calibrated ratcheting compression tool sized for the connector and conductor gauge. De-energize and lock out the circuit at the panel before making any termination. Work must comply with applicable NEC requirements for conductor splicing, insulation, and enclosure fill. Do not use with aluminum conductors unless the connector is specifically listed for aluminum or copper-aluminum applications.

Technical Specifications

• Conductor Size: 1/0 AWG
• Connector Type: 2-Way Compression
• Material: Copper
• Color Code: Pink
• Package Quantity: 100 pieces
• Package Weight: 5.56 pounds per 100
• Package Dimensions (L x W x H): 12.5 inches x 6.4 inches x 4 inches
• UPC: 78621054509

Standard Information

• Brand: ABB
• Manufacturer Part Number: 54509
