ABB 3214 T&B BUSHING 1 1/2 SIZE PLASTIC

Product Description

The ABB 3214 is a T&B conduit bushing designed for use in electrical systems. This non-metallic component is made from polycarbonate, providing robustness and durability. It fits into knockout openings in metal boxes. The bushing has a trade size of one point nine eight four inches and an inside diameter of one point seven six inches, while the outside diameter measures two point two four inches. It is suitable for environments with a temperature rating of up to two hundred twenty-one degrees Fahrenheit.

• One-piece construction for easy installation
• Self-extinguishing and high impact strength material
• Designed for smooth wire pulling

Product Highlights

This conduit bushing enables quick and secure installation in knockouts, ensuring a safe electrical connection.

Product Information

Standard Information

• Manufacturer: ABB - Installation Products
• UPC: 78621003214

Technical Specifications

• Type: 1-Piece Knockout Non-Metallic
• Color: Black
• Material: Polycarbonate
• Series: 3210
• Temperature Rating: 221 deg F
• Trade Size: 1.984 in
• Dimensions: 1.76 in ID x 2.24 in OD
• Application: For use to bush knockout openings in metal boxes or enclosures
• Standards/Approvals: CSA C22.2 File No. 18.3|NFPA 70-2008|UL 514B|UL File No. E3803
