ABB 2RCS10X T&B Splice Heat-Shr 12-10 1.6

Product Description

ABB 2RCS10X is a heat shrinkable insulated butt splice connector designed for use with 12 to 10 AWG conductors. This connector has a length of one point six inches and is made from copper. It is suited for applications requiring reliable electrical connections in various environmental conditions.

• Heat shrinkable with electro tin plating.
• Self-insulated with heat shrinkable polyolefin and internally coated sealant.
• Creates a fully sealed connection to protect against corrosion and environmental exposure.

Product Highlights

This product is ideal for electricians and technicians needing durable and efficient connections.

Product Information

Standard Information

• Manufacturer: ABB - Installation Products
• UPC: 78621070328

Technical Specifications

• Type: Heat Shrinkable Insulated
• Color: Yellow
• Conductor Size: 12 to 10 AWG
• Dimensions: 0.31 in W
• Length: 1.6 in
• Material: Copper
• Series: RC Series
• Specifications: 1/4 in Maximum Insulation
• Standards/Approvals: CSA Certified, UL 94 V-0 Flammability Rating, UL Listed
• Temperature Rating: 150 deg C
• Voltage Rating: 600 VAC
