ABB 2RA18 Nylon-Insulated Butt Splice 600 Volt (100 ea) REPLACEMENT MPN

Product Description

The ABB 2RA18 is a nylon-insulated butt splice designed for wire connections between gauge sizes twenty-two to eighteen AWG. This product meets the requirements of MIL-T-7928 and is color-coded for easy identification based on wire size. The splice features an electro-tin plated copper construction with a voltage rating of up to six hundred volts.

• Compatible with wires in the range of #22-#18 AWG
• Maximum insulation diameter of 0.115 inches
• Temperature rating of one hundred five degrees Celsius

Product Highlights

The butt splice provides a secure connection with minimal effort. Wires are laid side by side in the connector for efficient crimping, creating a reliable joint.

Product Information

Standard Information

• Brand: ABB
• Manufacturer: Thomas & Betts Co

Technical Specifications

• Type: Nylon Insulated Butt Splice
• Material: Copper
• Color: Red
• Length: 1.19 inches
• Width: 0.18 inches
• Voltage Rating: 600 VAC
• Temperature Rating: 105 degrees C
• Conductor Size: 22-18 AWG
• Finish: Electro-Tin Plated
• Standards/Approvals: CSA Certified, UL 94 V-2 Flammability Rating, MIL-T-7928
