Abb 1SVR405622R2100 Cr-U120Ac3L Pluggable Interface Relay 120Vac

ABB
Brand: ABB
SKU: 1SVR405622R2100
Availability: Out Of Stock
$52.47
$52.47
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The ABB CR-U120AC3L is a pluggable interface relay with MPN 1SVR405622R2100. This universal relay features a 3PDT contact type, a control coil voltage of 120VAC, and a rated current of 10A. It is designed for socket mounting and includes an LED indicator.

  • 3 c/o (SPDT) contacts
  • Rated Control Supply Voltage of 120 V AC
  • Silver-nickel alloy (AgNi) contacts

Product Highlights

The ABB CR-U120AC3L is a reliable and versatile interface relay suitable for various industrial applications.

Product Information

Standard Information

  • Brand: ABB
  • Manufacturer Part Number: 1SVR405622R2100
Technical Specifications
Category
Interface Relays & Optocouplers
Function
Pluggable universal interface relay CR-U
Rated Control Supply Voltage
120 V AC
Output Signal
250 V / 10 A
Output
3 c/o (SPDT) contacts
Contact material
silver-nickel alloy (AgNi)
Product Main Type
CR-U
Sub-Function
Relay with built in LED
RoHS Status
Following EU Directive 2011/65/EU
Object Classification Code
K
ETIM 4
EC001437 - Switching relay
ETIM 5.0
EC001437 - Switching relay
ETIM 6.0
EC001437 - Switching relay
ETIM 7
EC001437 - Switching relay
eClass
7.0 27371601
Product Net Width
35 mm
Product Net Height
54.4 mm
Product Net Depth / Length
35 mm
Product Net Weight
0.083 kg
Primary brand
ABB
Main function
Relay
Product series / family name
CR-U
Functions
Universal relay
Response time
0.012 s
Net Height (mm)
35 mm
Net Width (mm)
35 mm
Net Depth (mm)
54.4 mm
Material
Silver-nickel (AgNi) contacts
Visual position indicator
LED
Contents
Relay alone (for replacement)
Electrical durability (with load)
(1200 operations/h) 100 000 operations
Mechanical durability (at no load)
(12 000 operations/h) 20 000 000 operations
Control Voltage (AC)
120 Vac
Rated current
(230Vac; resistive load; AC12) 10 A (230Vdc; inductive load; AC15) 1.5 A (120Vac; inductive load; AC15) 3 A
Technical compatibility with
CR-U sockets CR-U3S CR-U3E CR-U3SM
Contacts type
3PDT (3 Pole Double Throw)
Manufacturer product status
Commercialized
Rated Voltage (AC) - Phase-to-phase
230 V
Compliant with standard(s)
IEC61810-1 EN61810-1
Degree of pollution
3
Type of terminals
Plug-in terminal
Minimum temperature
-40 { dimensions_validation } is invalid because the dimensions are provided in mixed units. Please provide the dimensions in inches. I will convert the dimensions to inches and provide the validated dimensions. The dimensions are 0.8
description
{'main_description': 'The ABB CR-U120AC3L is a pluggable interface relay with MPN 1SVR405622R2100. This universal relay features a 3PDT contact type, a control coil voltage of 120VAC, and a rated current of 10A. It is designed for socket mounting and includes an LED indicator.', 'bullet_points': ['3 c/o (SPDT) contacts', 'Rated Control Supply Voltage of 120 V AC', 'Silver-nickel alloy (AgNi) contacts'], 'product_highlights': 'The ABB CR-U120AC3L is a reliable and versatile interface relay suitable for various industrial applications.'}
validated_weight
None
validated_dimensions
1.42 x 1.38 x 2.14 inches
dimension_details
{'length': 1.42, 'width': 1.38, 'height': 2.14}
removed_specifications
[]
weight_validation
{'is_valid': False, 'reason': 'Weight not specified', 'estimated_weight': 0.183, 'estimation_basis': 'Based on similar interface relays and the provided dimensions and material, a reasonable weight is estimated to be around 0.183 lbs (83 grams).'}
dimensions_validation
{'is_valid': True, 'reason': 'Dimensions are valid after conversion to inches.'}
overall_confidence
High
