Abb 1LE24212BB112AA3 Motor, 15 HP, 1800 RPM, SD100 IEEE, 460 V, 254T, NP

Product Description

The ABB 1LE24212BB112AA3 motor is a 15 HP SD100 IEEE motor. This AC electric motor is designed for IEEE-841/Petrochem applications. It features Class F insulation with a Class B temperature rise and is certified for Division 2 hazardous locations. The motor has IP55 protection against dust and water ingress, making it suitable for demanding applications.

• NEMA SD100 841
• Totally Enclosed Fan Cooled
• Cast Iron

Product Highlights

Premium efficient AC electric motor suitable for IEEE-841/Petrochem applications with a robust design and reliable performance.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: 1LE24212BB112AA3
• Country of Origin: MEXICO

Technical Specifications

• Catalog Number: 1LE24212BB112AA3
• Enclosure: TEFC
• Frame: 254T
• Frame Material: Cast Iron
• Frequency: 50.00 Hz
• Output @ Frequency: 10 HP @ 50 HZ
• Phase: 3
• Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
• Voltage @ Frequency: 460 V @ 60 HZ
• Haz Area Class and Group: CLI GP A,B,C,D; CLII GP F,G
• Haz Area Division: Division II
• Ambient Temperature: 40 00b0C
• Base Indicator: Rigid
• Bearing Grease Type: Polyrex EM
• Constant Torque Speed Range: 20:1
• Current @ Voltage: 19 A @ 460 V
• Design Code: B
• Duty Rating: CONT
• Efficiency @ 100% Load: 92.4 %
• Efficiency @ 50% Load: 92.3 %
• Efficiency @ 75% Load: 92.8 %
• Enclosure Modification: 841
• Front Face Code: Standard
• Insulation Class: F
• Inverter Code: Inverter Ready
• IP Rating: IP55
• KVA Code: G
• Lifting Lugs: Standard Lifting Lugs
• MLFB: 1LE24212BB112AA3
• Motor Lead Exit: Conduit Box
• Motor Lead Termination: Flying Leads
• Mounting Arrangement: F1
• No Load Current: 8.5 a
• Number of Poles: 4
• Overall Length: 25.80 IN
• Power Factor: 80
• Product Type: SD100 IEEE
• Pulley End Bearing Type: Ball
• Pulley Face Code: Standard
• RoHS Status: ROHS COMPLIANT
• Rotor Inertia: 1.68090 lb-ft2
• Service Factor: 1.15
• Shaft Diameter: 1.625 IN
• Shaft Extension Location: Pulley End
• Shaft Rotation: Reversible
• Speed: 1479 rpm
• Speed Code: Single Speed
• Motor Standards: NEMA
• Starting Current: 116.0 a
• Starting Method: Direct on line
• Thermal Device - Bearing: None
• Thermal Device - Winding: None
• Haz Area Temp Code: T3
• HP: 15
• RPM: 1800
• Mounting: Rigid
• Application: IEEE-841/Petrochem
• FLA: 19
• Base: Rigid Base
• F1 Mount: F1 Mount
• Bearing: DE Ball Bearing
• Rated Motor Output Power: 15 HP
• Rated Motor Speed: 1770 RPM
• Rated Motor Voltage: 460V
• Poles: 4
• Nominal Efficiency: 92.4
• Nominal Power Factor: 80
• Number of Speeds: 1 Speed
• Degree of Protection (IP): IP55
• Removable Feet: No
• Greaseable: No
• Hazardous Locations: CSA Certified
