Aalberts 94ALF20601A Apollo 94ALF-A Full Port Brass Ball Valve, 1-1/4 inch, Sweat x Sweat

Product Description

The Aalberts 94ALF20601A is a full port brass ball valve designed for reliable operation in various plumbing applications. This valve features a nominal size of one and one-fourth inches with a sweat x sweat connection. It can handle a maximum pressure of six hundred psi and has an opening size of one point twenty-six inches.

• Lead free brass construction
• Temperature rated from negative twenty to three hundred sixty-six degrees Fahrenheit
• PTFE seals and packing for durability

Product Highlights

This valve is suitable for general plumbing, HVAC applications, and potable water systems. It is ANSI certified lead free and includes a blow-out proof stem design for enhanced safety.

Product Information

Standard Information

• Brand: Aalberts
• MPN: 94ALF20601A

Technical Specifications

• Type: Full Port
• Nominal Size: 1-1/4 inch
• Connection Type: Sweat x Sweat
• Opening Size: 1.26 inch
• Body Material: Lead Free Brass (DZR)
• Ball Material: 316 Stainless Steel
• Seat: PTFE
• Seal: PTFE
• Stem: Lead Free Brass
• Packing: PTFE
• Temperature Rating: -20 to 366 Deg F
• Standards: MSS SP-110, NSF/ANSI 61-8, NSF/ANSI 372, IAPMO IGC 157 (cUPC), ANSI Z21.15 (1/2 psi), ASME B16.44 (5 psi), UL 258, FM 1140
