Product Description
The Aalberts 94ALF20501A is a full port brass ball valve. It has a nominal size of one inch with sweat x sweat connections. This valve meets a maximum pressure rating of six hundred psi. It features two ports, with an opening size of zero point ninety-five inches. The body is made from lead free brass, and it incorporates a lead free chrome plated brass ball. The valve also includes a PTFE seat and seal along with a lead free brass stem. It is designed for temperatures ranging from minus twenty to three hundred sixty-six degrees Fahrenheit. The valve adheres to standards including MSS SP-110 and NSF/ANSI 61-8.
- Lead free materials for safe use
- Available in a standard one inch size
- Meets multiple industry standards
Product Highlights
This ball valve is suitable for plumbing, gas, fuels, and fire protection applications, making it a versatile choice for contractors.
Product Information
Standard Information
-
Category: Valves & Accessories > Plumbing Shut-Off Valves > Ball Valves
-
UPC: 670750059919
Technical Specifications
-
Series: 94ALF-A
-
Type: Full Port
-
Nominal Size: 1 inch
-
Connection Type: Sweat x Sweat
-
Opening Size: 0.95 inch
-
Body Material: Lead Free Brass (DZR)
-
Seat: PTFE
-
Ball Material: Lead Free Chrome Plated Brass (DZR)
-
Seal: PTFE
-
Stem: Lead Free Brass
-
Packing: PTFE
-
Temperature Rating: -20 to 366 Deg F
-
Dimensions: B: 3.23 inch; C: 2.45 inch; D: 4.53 inch; E: 1.13 inch
