A.y. Mcdonald 6190-149 Sump Pump 1/3 Hp 1.5 in 115V

Product Description

The A.Y. McDonald 6190-149 is a cast iron submersible sump pump designed for residential and light commercial dewatering applications. Rated at 1/3 horsepower and operating on 115 volts, this pump delivers up to 60 GPM through a 1.5-inch discharge outlet. It ships with a 10-foot power cord and uses a magnetic switch for automatic float-free level sensing. The cast iron construction provides durability in pit environments where lesser materials corrode or crack over time. Licensed plumbers and pump technicians are the primary installers for this type of unit.

The 6190-149 fits standard residential sump pits and is appropriate for basements, crawl spaces, and below-grade mechanical rooms that accumulate groundwater or stormwater intrusion. The 1.5-inch discharge outlet is compatible with common PVC discharge piping configurations. The magnetic switch design eliminates a mechanical float arm, reducing the chance of the switch fouling against pit walls or debris. This makes it well suited for narrow or irregularly shaped sump pits where float clearance is limited.

Key Features

• 1/3 HP motor rated for 115-volt single-phase operation
• 60 GPM flow rate through 1.5-inch discharge outlet
• Magnetic switch replaces mechanical float for reliable automatic operation
• Cast iron construction for long service life in wet pit environments
• 10-foot power cord for reach to standard receptacles without extension cords

Compatibility

Designed as an OEM-style replacement or direct installation sump pump for residential and light commercial sump pit applications using 1.5-inch discharge piping on a standard 115-volt circuit.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and IPC guidelines. Disconnect power at the breaker before lowering the pump into the pit or making any discharge connections. Verify the discharge line includes a weep hole just above the pump outlet to prevent air lock on startup. Do not run the pump dry, as the motor relies on the surrounding water for cooling.

Technical Specifications

• Horsepower: 1/3 HP
• Voltage: 115 volts
• Flow Rate: 60 GPM
• Discharge Size: 1.5 inches
• Cord Length: 10 feet
• Switch Type: Magnetic
• Material: Cast Iron
• Weight: 25 pounds

Standard Information

• Brand: A.Y. McDonald
• Manufacturer Part Number: 6190-149
