A.Y. Mcdonald 5426-032 72105 3/4 Ball Valve Push Fit NL

Product Description

The A.Y. MCDONALD 5426-032 72105 3/4 Ball Valve Push Fit NL is designed for use on copper, PEX, and CPVC tubing, eliminating the need for soldering, crimping, or solvent welding. It is designed for above-ground indoor water applications and complies with all applicable standards. Pressure rated at 200 PSIG from 0° to 200°F.

• No-Lead Push Fit Fittings
• Eliminates the need for soldering, crimping, or solvent welding
• Ideal for use on plumbing, water, and hydronic heating systems

Product Highlights

This ball valve features a special rubber O-ring and stainless steel gripper ring for a permanent connection in seconds.

Product Information

Standard Information

• Brand: A.Y. MCDONALD
• Manufacturer Part Number: 5426-032

Technical Specifications

• Part Type: Ball Valve
• Series: 72105
• Inlet Connection: Push Fit
• Outlet Connection: Push Fit
• Inlet Connection Size: 3/4
• Outlet Connection Size: 3/4
• Ball Plug: Ball
• Product Line: Plumbing
• Product Class: 150
• Commercial Category: Plumbing Valves
• Commercial Sub Category: Ball Valve - Push
• Commercial Style: CTS X CTS
• Model #: 5426-032
• Description: 3/4 in.
• Main Category: Underground Utility Supplies
• Typical applications: Above ground plumbing, water systems and hydronic heating systems
• Use with: Pex tubing in accordance with ASTM F-876 and F-877 Copper tubing in accordance with ASTM B88 CPVC tubing in accordance with ASTM D2846/2846M-99
• Material: Body - Forged no-lead brass O-Ring - EPDM Rubber Gripper Ring - 316 Stainless Steel Stiffener - Polysulfone Plastic Parts - Acetal (POM)
• Conformance: Manufactured in Accordance to ANSI/ASSE 1061 CSA B137.5 Listed, Adapter threads to ANSI B1.20.1 Adapter solder ends to ANSI B16.18
• Pressure and Temperature: Push-Fit Fittings are pressure rated at 200 psig (13.8 bar) over a temperature range from 0ºF to 200ºF (-18ºC to 93ºC)
• Quality Asssurance: The robust Push-Fit design has been tested and certified to meet ASSE 1061, ANSI / NSF 14, and ANSI / NSF 61 standards for materials and performance. All components are CNC machined, precision stamped, or injection molded to insure 100% conformance to design specifications. The end user may specify and install Push-Fit products with confidence.
• Item dimensions L x W x H: 19 x 19 x 88 millimeters
• Inlet connection type: Cross Linked Polyethylene
• Outlet connection type: PEX
• Global Trade Identification Number: 00535656682770
• Manufacturer: 72105 3/4 Ball Valve CTS No Lead
• Number of Items: 1
• UPC: 535656682770
• Item Dimensions: 19 x 19 x 88 millimeters
• Material Type: Copper
