A.Y. Mcdonald 5420-207 72050T Swing Check Valve - No-Lead 2-1/2 in

Product Description

The A.Y. MCDONALD 5420-207 72050T Swing Check Valve is constructed from heavy duty no-lead bronze and is recommended for residential and commercial applications. It features positive shut-off with various inlet configurations. Threads conform to ANSI B1.20.1 and is directional. NSF / ANSI 372 & NSF / ANSI 61 certified.

• FNPT x FNPT, 200 WOG
• Metal to metal seat
• Directional

Product Highlights

The A.Y. McDonald 5420-207 Swing Check Valve is ideal for plumbing applications. It has a brass body and trim, and Fiber-H softgoods.

Product Information

Standard Information

• Brand: A.Y. MCDONALD
• Manufacturer Part Number: 5420-207

Technical Specifications

• Part Type: Swing Check
• Series: 72050T
• Inlet Connection: FNPT
• Outlet Connection: FNPT
• Inlet Connection Size: 2 1/2
• Outlet Connection Size: 2 1/2
• Product Line: Plumbing
• Product Class: 150
• Commercial Category: Plumbing Valves
• Commercial Sub Category: Check Valves - NL Brass Swing
• Commercial Style: FNPT x FNPT
• MPN: 5420-207
• Model #: 5420-207
• Description: 2-1/2 in.
• Body Material: Brass
• End Style: FNPT
• Inlet to Outlet Length: 5.14 in
• Low Lead Compliance: Yes
• Media: Water
• Nominal Size: 2-1/2 in
• Softgoods Material: Fiber-H
• Top to Inlet Center: 3.09 in
• Trim Material: Brass
• Type: Directional
• Manufacturer: A.Y. McDonald
• Size: 2-1/2 in.
