A.Y. Mcdonald 5420-131 72035T Gate Valve 2 inches FNPT

Product Description

The A.Y. MCDONALD 5420-131 72035T gate valve is constructed from heavy-duty no-lead bronze, designed for residential and commercial applications, and provides positive shut-off. It features FNPT connections, a full port, and a handwheel actuator. Threads conform to ANSI B1.20.1 and solder ends conform to ANSI B16.18.

• Brass construction
• Full port design
• FNPT connection
• Gate valve type

Product Highlights

Full port gate valve with FNPT connections and no-lead brass construction.

Product Information

Standard Information

• Brand: A.Y. MCDONALD
• Manufacturer Part Number: 5420-131

Technical Specifications

• Maximum Temperature Rating: 180°F
• Threads Conform to: ANSI B1.20.1
• Pressure Rating: 200 WOG, 125 WSP
• Compliance: Complies with NSF/ANSI 372-2010, NSF-61 Annex G
• Stem Type: Non-rising stem
• Solder Ends Conform to: ANSI B16.18
• Part Type: Full Port Gate Valve
• Series: 72035T
• Inlet Connection: FNPT
• Outlet Connection: FNPT
• Inlet Connection Size: 2
• Outlet Connection Size: 2
• Material: NL Brass
• Valve Size: 2
• Product Line: Plumbing
• Product Class: 161
• Commercial Category: Plumbing Valves
• Commercial Sub Category: Gate Valve - NL
• Commercial Style: FNPT x FNPT
• Actuator Type: Handwheel
• Body Material: Bronze
• End Style: FNPT
• Hand Wheel Diameter: 3.52
• Inlet to Outlet Length: 2.7
• Manufacturer: A.Y. McDonald
• Manufacturer #: 5420-131
• Media: Water
• Port Type: Full
• Softgoods Material: Graphite Gland Packing
• Top to Inlet Center: 5.98
• Trim Material: BRASS
• Model #: 5420-131
• Description: 2 in.
• Nominal Size: 2 in
