A.Y. Mcdonald 5420-130 Full Port Gate Valve 1-1/2 in. FNPT

Product Description

The A.Y. McDonald 5420-130 is a full port gate valve with FNPT connections. This no-lead valve features a non-rising stem and threads that conform to ANSI B1.20.1. It is suitable for commercial, gas, oil, residential, and water applications.

• Full Port Gate Valve
• No-Lead
• FNPT x FNPT
• 200 WOG
• 125 WSP

Product Highlights

Full port gate valve with FNPT connections, non-rising stem, and no-lead construction.

Product Information

Standard Information

• Brand: A.Y. MCDONALD
• Manufacturer Part Number: 5420-130

Technical Specifications

• Part Type: Full Port Gate Valve
• Series: 72035T
• Inlet Connection: FNPT
• Outlet Connection: FNPT
• Inlet Connection Size: 1 1/2
• Outlet Connection Size: 1 1/2
• Material: NL Brass
• Valve Size: 1-1/2 in
• Product Line: Plumbing
• Product Class: 161
• Commercial Category: Plumbing Valves
• Commercial Sub Category: Gate Valve - NL
• Commercial Style: FNPT x FNPT
• Model #: 5420-130
• Description: 1-1/2 in.
• ANSI: ANSI 372, ANSI B1.20.1, ANSI B16.18
• End Connection 1: FPT
• End Connection 2: FPT
• End Connections: FPT
• FM Approved: No
• Handle Material: Cast Iron
• Lead Law Compliance Level: Lead Law Compliant and Certified
• Lead Law Compliant: Yes
• Maximum Temperature: 180
• NSF: NSF 372, NSF 61-G
• NSF Certified: Yes
• Pressure Class: 200#
• Recommended Valve Application: Commercial, Gas, Oil, Residential, Water
• UL Listed: No
• UPC: 053565548050
• Valve Body Material: Brass
• Valve Bonnet Type: Threaded
• Valve Disc Material: Brass
• Valve Operator: Handwheel
• Valve Port Opening: Full Port
• Valve Stem: Non-rising
• Valve Type: Gate Valve
