A.Y. McDonald 4901-163 10710Y 1 GAS BALL VALVE CSA YELLOW HANDLE

Product Description

A.Y. McDonald 4901-163 is a quarter-turn ball valve designed for low-pressure gas applications. This two-piece valve features a nominal size of one inch and is suitable for non-potable use. The valve operates between temperatures of negative forty to one hundred twenty-five degrees Fahrenheit. The media type is gas, and it is constructed with a chrome-plated brass ball and a forged brass body.

• Blow-out proof stem for enhanced safety
• PTFE gland packing and ball disc packing
• Designed for commercial and industrial applications

Product Highlights

This valve is essential for systems where reliable gas flow control is required. It is built to meet several standards including ANSI B1.20.1 and UL 842.

Product Information

Standard Information

• Manufacturer: A.Y. McDonald MFG CO
• Model: 10710Y

Technical Specifications

• Ball Material: Chrome Plated Brass
• Body Material: Forged Brass
• End Style: FNPT
• Inlet to Outlet Length: 2.87 inches
• Nominal Size: 1 inch
• Softgoods Material: PTFE
• Temperature Rating: -40 to 125 degrees Fahrenheit
• Top to Inlet Center: 1.66 inches
• Trim Material: Brass Stem
