A.Y. MCDONALD 10685B 1/2 in. Female Bronze Flat/Tee Head Plug Valve with Check

Product Description

The A.Y. MCDONALD 10685B is a 1/2 inch female bronze flat/tee head plug valve designed for use in gas piping systems. It features a durable cast iron body suitable for applications where ambient temperatures range from -20 to 150 degrees Fahrenheit.

• Designed for above-ground gas piping systems
• Full port flow capability
• Includes brass plug for reliability

Product Highlights

This valve is tamper-proof and relubable, ensuring long-lasting functionality. It meets ANSI/ASME specifications and supports threaded connections, making it an essential component for gas installations.

Product Information

Standard Information

• Model Number: 10685B
• Brand: A.Y. MCDONALD

Technical Specifications

• Material: Cast Iron
• Height: 3.16 inches
• Length: 3.14 inches
• Weight: 1.625 pounds
• Inlet Type: FNPT
• Outlet Type: FPT
• Maximum Pressure Rating: 175 PSI
• Maximum Temperature Rating: +150 degrees F
• Minimum Temperature Rating: -20 degrees F
• Catalog Number: 10685B
• Special Features: Threaded
• Specifications Met: ANSI/ASME B1.20.1, ASME B16.33
