Honeywell M7164A1017 Modutrol IV Motor 35 lb-in 24V

Product Description

The Honeywell M7164A1017 Modutrol IV Motor is designed for precise control of dampers and valves in HVAC systems. This 24-volt motor ensures reliable operation with its non-spring return mechanism, capable of handling 35 pounds-inch torque.

• Robust construction offers NEMA 3 weather protection when mounted upright.
• Features dual-ended shafts for flexible installation and operation.
• Adjustable stroke from 90 to 160 degrees for versatile application.

Product Highlights

Honeywell's M7164A1017 motor is engineered for efficient performance with a fixed torque output across a wide voltage range. It includes integral auxiliary switches that can be factory or field-mounted.

Product Information

Standard Information

• Control Signal: Proportional, 10.5 to 13.5 Vdc
• Mounting: Foot-mounted for stable installation.

Technical Specifications

• Power Consumption: 10 VA
• Frequency: 50 Hz / 60 Hz
• Temperature Range: -40 to 150F
• Deadweight Load on Shaft: 200 lbs (either end), 300 lbs (combined)
• Auxiliary Switch Ratings: AFL - 120 Vac: 7.2A, 240 Vac: 3.6A
