3M SC0040 Stem Connector 35 kVAC 4/0 AWG

Product Description

The 3M SC0040 Stem Connector is designed for connecting copper or aluminum conductors in overhead lines. It features a tin-plated aluminum barrel, providing durability for various electrical installations. This connector is suitable for use with conductors rated up to thirty-five kVAC. The design incorporates a factory crimped and sealed tin-plated copper stem for effective aerial line connections.

• Rated for use with 4/0 AWG stranded conductors
• Stem diameter is 0.31 inches and stem length is six inches
• Compatible with 3M cold shrink terminations

Product Highlights

Reliability is enhanced by its tin plating and crimped construction, ensuring long-lasting performance in various electrical applications.

Product Information

Standard Information

• Brand: 3M
• MPN: SC0040

Technical Specifications

• Voltage Rating: 35 kVAC
• Conductor Size: 4/0 AWG
• Conductor Type: Stranded
• Material: Aluminum/Copper
• Stem Diameter: 0.31 inches
• Stem Length: 6 inches
• Finish: Tin Plated
• Series: SC Series
