3M IT1.500BK9S 3M ITCSN-1500-9 Heavy Wall Shrink Tubing

Product Description

3M IT1.500BK9S is a heavy wall heat shrink tubing designed for various electrical applications. This cable sleeve offers excellent resistance to abrasion, corrosion, and chemicals. It has a shrink ratio of 3:1 suitable for electrical insulation of up to one kV rated applications. The construction from cross-linked polyolefin ensures that it provides a moisture seal for effective protection.

• Heavy wall for strong structural integrity
• Resistant to harsh environmental conditions
• Designed for easy installation and use in multiple applications

Product Highlights

This tubing is ideal for insulating secondary splices, direct buried, and submersible repairs. It withstands a temperature range from negative sixty-seven to two hundred thirty degrees Fahrenheit.

Product Information

Standard Information

• Catalog Number: IT1.500BK9S
• Brand: 3M

Technical Specifications

• Material: Polyolefin
• Length: 9 inches
• Voltage Rating: 600 VAC
• Shrink Ratio: 3:1
• Max Voltage: 1 kV
• Operating Temperature: -55 to 110 degrees Celsius
• Dielectric Strength: 500 V/mil
• Country of Origin: USA
