3M CTB2X1BGA-C Cable Tie Mounting Base Foam Backed Adhesive 2 x 1 in

Product Description

3M CTB2X1BGA-C is a foam-backed adhesive cable tie mounting base made of ABS for securing wire bundles and harness components. The two-way base measures 2.00 x 1.00 x 0.35 in with a slot width of 0.21 in and slot height of 0.18 in, and is compatible with miniature, intermediate, and standard cable ties. It is RoHS compliant and rated for -40�F to 185�F operating temperature for indoor or outdoor use.

• Foam-backed adhesive mount with two-way tie entry for flat-surface installation
• ABS construction; overall size 2.00 x 1.00 x 0.35 in; slot size 0.21 in x 0.18 in
• Compatible with miniature, intermediate, and standard cable ties; RoHS compliant; UL approved

Product Highlights

Foam-backed adhesive ABS base; two-way entry; fits 0.21 in ties; RoHS compliant; -40�F to 185�F operating range

Product Information

Standard Information

• Brand: 3M
• Manufacturer Part Number: CTB2X1BGA-C
• Country of Origin: United States

Technical Specifications

• Manufacturer: 3M Electrical Products
• Brand: 3M
• Manufacturer Part Number: CTB2X1BGA-C
• Type: Cable tie mounting base
• Mounting Type: Foam-backed adhesive
• Material: ABS
• Length: 2.00 in (50.8 mm)
• Width: 1.00 in (25.4 mm)
• Height: 0.35 in (8.9 mm)
• Slot Width: 0.21 in (5.1 mm)
• Slot Height: 0.18 in (4.5 mm)
• Tie Width: 0.21 in
• Tie Entry: 2-way
• Compatible Tie Types: Miniature, intermediate and standard cable ties
• RoHS Compliance: RoHS 2011/65/EU compliant without exemption
• UL Approval: UL approved
• Country of Origin: United States
• Made in USA: Yes
• Minimum Operating Temperature: -40 �F (-40 �C)
• Maximum Operating Temperature: 185 �F (85 �C)
• GTIN: 00054007062905
• UPC: 054007062905
