3M 8561 Cold Shrink 3/C Cable Breakout Boot

Product Description

The 3M 8561 is a cold shrink 3-way cable breakout boot that protects the phase leg breakout of medium voltage power cables. Made from silicone rubber, it is designed to shield cables from environmental hazards. The boot comes with a pre-installed removable plastic core, allowing for quick installation without special tools.

• Inner diameter expands to one point ninety-four inches.
• One point three inches inner diameter is achieved when the boot fully recovers.
• Compatible with cold shrink silicone rubber termination products.

Product Highlights

This boot provides an excellent seal for environmental protection and cable insulation.

Product Information

Standard Information

• Manufacturer: 3M
• Part Number: 8561

Technical Specifications

• Type: 3-Way Cold Shrink Highly Flexible
• Color: Dark Gray
• Material: Silicon Rubber
• Length: 5 inches
• Inner Diameter Expanded: 1.94 inches
• Inner Diameter Recovered: 1.3 inches
• Number of Legs: 3
• Voltage Rating: 35 kV
• Temperature Rating: 180 degrees Celsius
