3M 7624-T-110 Cold Shrink QT-III Termination Kit 5-15 Kv Insulation Od 0.83-1.53

Product Description

3M 7624-T-110 Cold Shrink QT-III Termination Kit is designed for efficient termination of indoor and outdoor medium voltage cables. This kit provides reliable performance and ease of installation. It supports multiple voltage ratings and conductor sizes, making it versatile for various applications.

• Includes three non-skirted, one-piece, three-phase cold shrink terminations.
• Compatible with solid dielectric shielded power cables rated 5 kV to 15 kV.
• Features high dielectric constant material regulating electric field stress distribution.

Product Highlights

Ideal for use in indoor and weather-protected applications, this termination kit meets IEEE standards for performance and safety, ensuring a void-free seal for optimal cable integrity.

Product Information

Standard Information

• Brand: 3M
• MPN: 7624-T-110

Technical Specifications

• Voltage Rating: 15 kilovolt
• Conductor Size: 500 to 750 kcmil (5 kV), 350 to 700 kcmil (8 kV), 4/0 AWG to 500 kcmil (15 kV)
• Cable Type: Tape shield, wire shield, UniShield
• Insulator Material: Silicone rubber
• BIL Rating: 110 kilovolt
• Installed Length: 12 inches
• Contents: Three Hi-K silicone rubber terminations, three pre-formed ground braids, three constant force springs, six mastic seal strips, one cable preparation kit, three copper foil shielding tape strips, one instruction sheet.
