3M 7100364639 Vhb Max-110gf Acrylic Foam Tape 1 in X 36 Yd

Product Description

The 3M 7100364639 is a double-sided acrylic foam tape engineered for high-load bonding in demanding industrial environments. Sold as Max-110GF, it carries a gray foam core that is 1.1 mm (45 mil) thick and bonds surfaces with overlap shear strength reaching up to 470 psi. The tape is wound on a film liner in 1-inch-wide by 36-yard rolls, with 9 rolls per case. It is designed as a direct alternative to mechanical fasteners, certain forms of welding, and liquid adhesives where a clean, permanent bond is required. Fabricators, assembly technicians, and industrial maintenance professionals use this tape when rigid fastening methods are impractical or when weight reduction and cleaner aesthetics are priorities.

Max-110GF is suited to industrial assembly and fabrication tasks where mechanical fasteners cannot be used or where bond-line width must be minimized. Typical applications include attaching metal panels, plastic components, trim, and signage to structural substrates in transportation, construction, and manufacturing settings. Its 1.1 mm thickness places it in the mid-range of the VHB Max series, making it appropriate for surfaces with moderate surface irregularity. The film liner supports clean, precise application in both manual and semi-automated tape application processes.

Key Features

• Overlap shear strength up to 470 psi (3.24 MPa) for high-load bonding applications
• 45 mil (1.1 mm) foam core accommodates moderate surface irregularity and gap-filling
• Double-sided acrylic foam construction bonds dissimilar materials without mechanical fasteners
• Film liner supports accurate positioning and clean peel during application
• Gray color for visual contrast during installation and inspection
• Replaces mechanical fasteners, welding, and liquid adhesives to reduce assembly complexity

Compatibility

Designed as a high-strength bonding solution for industrial assembly applications requiring replacement of mechanical fasteners or liquid adhesives on metal, plastic, and composite substrates.

Installation Notes

Surface preparation is critical for maximum bond strength — clean substrate surfaces thoroughly to remove dust, oils, and contaminants before application. Apply firm, even pressure across the full tape surface to ensure full contact with both substrates. Allow adequate dwell time after assembly before applying load, as acrylic foam adhesives continue to build bond strength over the first 72 hours. Follow all applicable workplace safety and material handling guidelines during installation.

Technical Specifications

• Tape Width: 1 inch
• Tape Length: 36 yards per roll
• Thickness: 45 mil (1.1 mm)
• Color: Gray
• Liner Type: Film Liner
• Overlap Shear Strength: Up to 470 psi (3.24 MPa)
• Construction: Double-sided acrylic foam
• Case Quantity: 9 rolls per case

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100364639
