3M 7100204092 Pleated Air Filter 16x25x2 Merv 11

Product Description

The 3M 7100204092 is an electrostatic pleated air filter designed for forced-air HVAC systems requiring a 16 x 25 x 2 inch filter slot. Rated MERV 11 with 88% particle capture efficiency, it captures finer airborne particles than standard fiberglass or low-MERV media, making it suitable for residential and light commercial applications where indoor air quality is a priority. The filter media is polypropylene with an integrated frame that maintains shape under normal system static pressure. Licensed HVAC technicians and IAQ-focused contractors typically specify this filter tier for systems serving occupants with moderate sensitivity to dust, pollen, and fine debris.

This filter fits standard 16 x 25 x 2 inch filter housings found in residential gas furnaces, heat pumps, air handlers, and packaged rooftop units that accept that nominal slot size. Its electrostatic polypropylene media generates a passive charge that attracts and holds fine particulate without the added restriction associated with higher-MERV synthetic media. It is a practical replacement choice for service technicians performing routine seasonal maintenance or filter changeout calls.

Key Features

• MERV 11 rating with 88% particle capture efficiency
• Electrostatic polypropylene media for passive charge-based particle attraction
• Integrated frame maintains filter geometry and prevents bypass around edges
• Nominal size 16 x 25 x 2 inches; actual dimensions 15.81 x 24.81 x 1.81 inches
• Single-piece construction — no assembly required at installation

Compatibility

Designed as a replacement filter for forced-air HVAC systems — including gas furnaces, air handlers, and heat pumps — that accept a nominal 16 x 25 x 2 inch filter. Verify actual filter slot dimensions against the actual dimensions of 15.81 x 24.81 x 1.81 inches before ordering.

Installation Notes

Filter replacement is typically performed by HVAC technicians or trained maintenance personnel. Always shut down the air handling unit at the thermostat and at the disconnect before removing or inserting the filter. Confirm airflow-direction arrows on the filter frame align with system airflow before closing the access panel. Filters at MERV 11 can increase system static pressure; verify the existing blower and ductwork are rated to handle the additional restriction.
