3M 7100188877 Filtrete Micro Allergen Filter 12x20x1

Product Description

The 3M 7100188877 is a Filtrete Micro Allergen Reduction filter designed to capture both microscopic and large airborne allergens in residential forced-air HVAC systems. Sized at 12 inches x 20 inches x 1 inch, it fits standard 1-inch filter slots found in most residential air handlers and furnaces. The filter targets microscopic particles such as dust, smoke, and smog, as well as larger allergens including mold spores and pet dander. Rated for a 3-month service interval, it is a direct drop-in replacement for any compatible 1-inch filter slot and is handled by HVAC technicians and qualified installers during routine preventive maintenance visits.

This filter is suited for residential forced-air heating and cooling systems where indoor air quality is a service priority. It is commonly installed in applications where occupants have allergy or asthma concerns, or where dust and particulate control is required. The 12 x 20 x 1 inch form factor is one of the most common residential filter sizes, making it widely applicable across a broad range of residential air handlers, furnaces, and heat pumps equipped with a standard 1-inch media slot.

Key Features

• Captures microscopic allergens including dust, smoke, and smog particles
• Also reduces large allergens such as mold spores and pet dander
• Standard 1-inch depth fits most residential filter housings without modification
• Rated for approximately 3 months of service life under typical residential conditions
• Lightweight at 0.49 pounds for easy single-tech handling and installation

Compatibility

Designed as an OEM-style drop-in replacement for residential forced-air HVAC systems requiring a 1-inch media filter in a 12 inches x 20 inches x 1 inch slot.

Installation Notes

Air filters of this type are installed by HVAC technicians during routine maintenance or by knowledgeable homeowners. Before replacing the filter, set the thermostat to off and shut down system airflow at the air handler or furnace. Confirm airflow direction arrows on the filter frame match the direction of airflow into the unit before securing the filter housing. Dispose of the used filter in a sealed bag to prevent re-release of captured particulates.

Technical Specifications

• Filter Size: 12 inches x 20 inches x 1 inch
• Filter Depth: 1 inch
• Service Life: 3 months
• Weight: 0.49 pounds
• UPC: 00051111098196

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100188877
